Mobile LED lighting tower driven by 5kW Portable diesel generator Small lift lighthouse
JLTMT-5K
1. 4x400 watt lamps provide maximum illumination
2. Telescopic mechanical lifting, 3-section mast up to 4.5 meters high
3. The mast with self-locking function makes work safer
4. The lighthouse is equipped with a silent diesel generator for convenient power supply
5. The quiet and reliable diesel engine provides "flicker free" operation.
6. Manual winch for lifting mast (optional electric lifting)
◆ Suitable for situations where illumination needs to be changed at any time,
Especially in disaster relief, large-scale assembly, engineering maintenance, docks, and airports.
2. Telescopic mechanical lifting, 3-section mast up to 4.5 meters high
3. The mast with self-locking function makes work safer
4. The lighthouse is equipped with a silent diesel generator for convenient power supply
5. The quiet and reliable diesel engine provides "flicker free" operation.
6. Manual winch for lifting mast (optional electric lifting)
◆ Suitable for situations where illumination needs to be changed at any time,
Especially in disaster relief, large-scale assembly, engineering maintenance, docks, and airports.
Quantity:
□Technical Parameter
| Model | JLTMT5K | |
| Lamp post | Maximum height | 4.5m |
| Lifting method | Manual | |
| Lifting method | Mechanical winch | |
| Number of lamp posts | three | |
| Rotation angle | three hundred and sixty | |
| Lamp holder | Total power of the lamp | 4 x 400w |
| Lamp type | astigmatism | |
| Luminous flux | 4 x 25000 lumens | |
| Voltage | 230V | |
| frequency | 50Hz | |
| service life | 50000 hours | |
| working temperature | ≤85℃ | |
| Connection protection index | IP54 | |
| Range of illumination | 1000㎡ | |
| trailer | Supporting feet | 4 x Manual |
| Wheel size | 25.4cm (10") | |
| Wind resistance capability | ≤ Level 4 | |
| braking system | Parking brake | |
| Generator Set | model | JD6000SE |
| Rated power | 50Hz/4.5kw | |
| maximum power | 50Hz/5.0kw | |
| Engine type | JD186FA | |
| speed | 50Hz/3000rpm | |
| Engine type | Single cylinder 4-stroke air-cooled | |
| Startup method | Electric start | |
| electric machinery | 2-pole, brushed | |
| Fuel tank capacity | 15L | |
| Fuel consumption at full load | 1.85L/h | |
| working hours | 8h | |
| Control system | Pointer instrument panel key control | |
| Socket | two | |
| Packaging and weight | Dimensions unfolded: length * width * height | 1500*1500*4500 |
| Dimensions: folded length * width * height | 1150*820*2400 | |
| Net weight | 290kg | |
□Product Display
