3 inch diesel water pump,diesel high pressure water pump,diesel irrigation water pump

Engine 178fa 3-Inch Agricultural Water Pump/Diesel HighPressure Water Pump

DWP80
Payment: T/T Or L/C
Product Origin: Fuzhou, China
Color: Optional
Shipping Port: Fuzhou, China
Lead Time: 25-30days
Quantity:
Contact Now
add to cart
Economical Running
Equipped with JLT-POWER engines, JLT-POWER pumps assure superior combustions efficiency and minimized fuel consumption.

Portability
Adopted special alloy frame, largely reduced the weight and assures simple use.

A Wide Range
Excellent and advanced impeller ensures water supply in a wide range.

Durable Construction
The principal parts of each pump are reinforced for superior wear resistance and corrosion resistance.

Easy Maintenance
Cleaning the inside casing can be done simply by just removing a few bolts.


Powered by self-made reliable engines,JLT water pumps have superior durability with high performance-price ratio. Thanks to the Cathode Electrophoresis Coating in-house, which results in outstanding rust esistance of frames.


 ModelDWP80
TypeClarified water pump
Suction (mm)80 ( 2inch)
Rated Capacity (m3/h)60
Discharge Port Dia (mm)80
Self-Priming Time (s/4m)120
Max.Head (m)28
Max.Suction Head (m)8
ModelJP178FA
Type4-stroke,single cylinder wiht air-cooled gasoline engine
Bore x Stroke(mm)78x64
Displacement (ml)305
Max.output (HP/rpm)6.0/3600
FuelDiesel
Fuel Tank Capacity(L)3.3
Fuel consumption (g/kw.h)≤282
Lubrication OilSAE10W/30
Lubrication Oil Capacity (L)1.1
Starting SystemRecoil and Electric
Operating Noise Level (7m) dB(A)95
Dimensions LxWxH(mm)565x515x600
Net Weight (kg)50
Gross Weight（kg）52
20/40FT Load Qty132/280
