Engine 186FA 4-Inch Agricultural Water Pump/Diesel HighPressure Water Pump

DWP100

Payment: T/T Or L/C
Product Origin: Fuzhou, China
Color: Optional
Shipping Port: Fuzhou, China
Lead Time: 25-30days

Quantity:

Contact Now

add to cart

Economical Running
Equipped with JLT-POWER engines, JLT-POWER pumps assure superior combustions efficiency and minimized fuel consumption.

Portability
Adopted special alloy frame, largely reduced the weight and assures simple use.

A Wide Range
Excellent and advanced impeller ensures water supply in a wide range.

Durable Construction
The principal parts of each pump are reinforced for superior wear resistance and corrosion resistance.

Easy Maintenance
Cleaning the inside casing can be done simply by just removing a few bolts.

Powered by self-made reliable engines,JLT water pumps have superior durability with high performance-price ratio. Thanks to the Cathode Electrophoresis Coating in-house, which results in outstanding rust esistance of frames.

Model	DWP100
Type	Clarified water pump
Suction (mm)	100 ( 4inch)
Rated Capacity (m3/h)	96
Discharge Port Dia (mm)	100
Self-Priming Time (s/4m)	180
Max.Head (m)	28
Max.Suction Head (m)	8
Model	JP186FA
Type	4-stroke,single cylinder wiht air-cooled gasoline engine
Bore x Stroke(mm)	86x72
Displacement (ml)	418
Max.output (HP/rpm)	10/3600
Fuel	Diesel
Fuel Tank Capacity(L)	5.4
Fuel consumption (g/kw.h)	≤282
Lubrication Oil	SAE10W/30
Lubrication Oil Capacity (L)	1.65
Starting System	Recoil and Electric
Operating Noise Level (7m) dB(A)	96
Dimensions LxWxH(mm)	665x525x640
Net Weight (kg)	70
Gross Weight（kg）	72
20/40FT Load Qty	108/228
